Solid Boron Cantilever and Super line natural diamond stylus

Dragon MC cartridge is the flagship model of Jasmine B&W porcelain cartridge series. It adopted the best solid boron cantilever, with 0.3x0.7mil, Gyger FG2, super line contact natural diamond Stylus.

Unique coil structure and an innovative suspension design

Electromagnetic conversion efficiency of cartridge increase about 10%, The sound is more sensitive and more delicate.

Blue and white porcelain shell, gives the sound of Chinese characteristics

Blue and white porcelain introduces a distinct Chinese cultural characteristics, pleasing to the eye and ear, It is the perfect combination of audio-visual .

Specification

    Type

    MC

    Shell

    Blue and white porcelain

    Stylus

    0.3x0.7mil, Gyger FG2, Natural diamond

    Cantilever

    Solid Boron

    Height

    17.5mm

    Weight

    16 g

    Internal Impedance(DC resistance)

    4 ohm (DC)

    Output Level

    0.26mv, 1KHz@ 33 1/2

    Freq. response

    10-55KHz +/-1dB

    Channel separation

    > 30dB@1KHz

    Channel balance

    < 0.5dB

    Recommended loading

    >= 30 ohm, 4 ohm (MC step-up transformer)

    Optimal Tracking Force

    1.2g ~ 2.5g ( 1.85g recommended )

    Optimal Tracking Angle

    20 degree

    Compliance

    15μm/mN

    Break-in Period

    50 hours
